Component And Parts

• Application
• R/C Winch and accessory installations

• Capacity
• Suitable for standard 1/10 scale servo winch

• Coating Type
• Anodized

• Components
• Main bracket, mounting hardware

• Dimension (L*W*H)
• 68mm x 46mm x 19mm

• Grade
• 6061-T6

• Hole Size
• M3 (3mm)

• Making Process
• Other, CNC Machined

• Material
• Other, Aluminum Alloy

• Mount Type
• Direct mount with screws

• Shape
• Rectangular with slotted holes

• Surface Finishing
• Matte anodized

• Surface Treatment
• Other, Anodized Black

• Thickness
• 3mm

• Tolerance
• 0.1mm

• Usage
• Mounting servo winch securely on R/C vehicles

• Weight
• 29g

• Application
• Construction, Furniture, Shelving

• Capacity
• Up to 50 kg

• Coating Type
• Rust Resistant

• Components
• Bracket with 4 mounting holes

• Dimension (L*W*H)
• 50mm x 50mm x 40mm

• Grade
• SS304

• Hole Size
• 6 mm

• Making Process
• Other, Press Formed

• Material
• Stainless Steel

• Mount Type
• Screw Mounted

• Shape
• L-Shaped

• Surface Finishing
• Smooth Matte

• Surface Treatment
• Other, Zinc Plated

• Thickness
• 3 mm

• Tolerance
• 0.2mm

• Usage
• Support for shelves, frames, furniture

• Weight
• 0.18 kg

• Application
• Interior and Exterior Doors

• Capacity
• Standard Door Fitting

• Coating Type
• Nickel Chrome Plated

• Components
• Lever handle, Spindle, Screws, Rosette Plate

• Dimension (L*W*H)
• 205 mm x 50 mm x 60 mm

• Grade
• SS304

• Hole Size
• 8 mm

• Making Process
• Other, Die Cast

• Material
• Stainless Steel

• Mount Type
• Door Mounted

• Shape
• Curved Lever

• Surface Finishing
• Satin/Matt

• Surface Treatment
• Other, Polished

• Thickness
• 2.5 mm

• Tolerance
• 0.2 mm

• Usage
• Residential, Commercial

• Weight
• 420 g

• Application
• Automotive, Electrical, Furniture, Electronics

• Capacity
• Standard / Customized Holding Force

• Coating Type
• Anti-corrosion Zinc/Nickel

• Components
• Spring Steel Base, Clip Arm

• Dimension (L*W*H)
• Customizable as per requirement

• Grade
• Industrial Grade

• Hole Size
• Customizable

• Making Process
• Other, Cold Rolled / Stamping

• Material
• Other, High Carbon Steel / Stainless Steel

• Mount Type
• Panel Mount / Clip-On

• Shape
• Spring Clip

• Surface Finishing
• Polished / Plated

• Surface Treatment
• Other, Zinc Plated / Nickel Plated / Plain

• Thickness
• 0.5 mm to 2 mm

• Tolerance
• 0.02 mm

• Usage
• Clamping / Fastening / Fixing Components

• Weight
• Lightweight (approx. 5-20 grams)

• Application
• Electrical Enclosures, Sheet Metal Assemblies

• Coating Type
• Zinc Coating

• Components
• Single Piece

• Dimension (L*W*H)
• 40mm x 20mm x 10mm

• Grade
• Commercial Grade

• Hole Size
• 6 mm

• Making Process
• Stamping

• Material
• Other, Galvanized Steel

• Mount Type
• Push Fit/Snap Fit

• Shape
• U-Shaped with Retaining Lips

• Surface Finishing
• Smooth

• Surface Treatment
• Other, Zinc Plated

• Thickness
• 1.2 mm

• Tolerance
• 0.2 mm

• Usage
• Panel Fixing/Assembly

• Weight
• Approx. 12 grams

• Application
• Electrical, Machinery Assemblies, Control Panel Mounting

• Coating Type
• Electro-Galvanized

• Components
• Single Piece

• Dimension (L*W*H)
• 150 mm x 100 mm x 30 mm

• Grade
• IS 2062

• Hole Size
• 8.5 mm

• Making Process
• Other, Pressed Sheet Metal Fabrication

• Material
• Other, Mild Steel

• Mount Type
• Wall Mounted or Base Mounted

• Shape
• Rectangular with Flanges

• Surface Finishing
• Smooth Matte

• Surface Treatment
• Other, Zinc Plated

• Thickness
• 2.5 mm

• Tolerance
• 0.2 mm

• Usage
• Industrial Mounting and Enclosures

• Weight
• 320 grams

• Application
• Construction, Plumbing, Industrial piping, HVAC installation

• Capacity
• Suitable for loads up to 2000 kg (varies by size)

• Coating Type
• Zinc coated / Powder coated / Galvanized

• Components
• Clamping U-bolt, Nut & Washer set

• Dimension (L*W*H)
• Varies as per requirement (Typical: 50mm x 80mm x 120mm)

• Grade
• SS304, SS316, IS 2062, EN 8 (as specified)

• Hole Size
• M6 to M20 (customized as per bolt size)

• Making Process
• Other, Forged / Machined / Thread Rolled

• Material
• Other, Mild Steel (MS), Stainless Steel (SS 304/316), Galvanized Iron

• Mount Type
• Bolt-on / Through-bolt

• Shape
• U-shaped with threaded ends

• Surface Finishing
• Corrosion-resistant finishing

• Surface Treatment
• Other, Hot Dip Galvanized / Electroplated / Plain

• Thickness
• 5 mm to 12 mm (customizable)

• Tolerance
• 0.2 mm

• Usage
• Pipe support, Fastening, or Clamping applications

• Weight
• Depends on size & material (Typical: 80g to 500g)

• Application
• Automotive, Electrical, Electronic Equipment, Machinery

• Capacity
• Suitable for moderate to heavy loads

• Coating Type
• Anti-corrosive coating

• Components
• Wave Washer (single or multi-wave profile)

• Dimension (L*W*H)
• Customizable as per requirement

• Grade
• AISI 304, 316

• Hole Size
• Standard and custom sizes available

• Making Process
• Other, Cold Formed / Stamped

• Material
• Stainless Steel

• Mount Type
• Insert between bearing and housing

• Shape
• Wave

• Surface Finishing
• Smooth

• Surface Treatment
• Other, Zinc Plated, Black Oxide, Plain

• Thickness
• 0.2 mm to 2 mm

• Tolerance
• 0.05 mm

• Usage
• Absorbs shock and provides flexible preload

• Weight
• Varies as per size

• Application
• Clamping, Mounting, Fastening, Wiring

• Capacity
• As per design specification

• Coating Type
• Zinc / Chrome / Powder

• Components
• Custom wire forms, Brackets, Clips, Springs

• Dimension (L*W*H)
• As per requirement

• Grade
• Commercial / Industrial Grade

• Hole Size
• Custom as per specification

• Making Process
• Other, Wire Forming, Bending, Stamping, Cutting

• Material
• Other, Mild Steel / Stainless Steel / Customized

• Mount Type
• Hole, Clamp, Welded, Bolted

• Shape
• Custom shapes (Round, Flat, Angled, etc.)

• Surface Finishing
• Smooth, Coated, Polished

• Surface Treatment
• Other, Zinc Plating / Powder Coating / Polishing

• Thickness
• 0.2 mm - 12 mm

• Tolerance
• 0.05 mm

• Usage
• Industrial, Automotive, Electrical Applications

• Weight
• As per dimensions and material

• Application
• Precision Sheet Metal Fabrication

• Capacity
• Heavy Duty (based on bending process)

• Coating Type
• Electro-Galvanized / Epoxy / as required

• Components
• Bending, Cutting, Holes as per design

• Dimension (L*W*H)
• As per drawing / customized

• Grade
• IS 2062 / Equivalent

• Hole Size
• Custom/As per customer drawing

• Making Process
• Other, CNC Sheet Bending

• Material
• Other, Mild Steel (MS)

• Mount Type
• Surface Mount, Bolt-On

• Shape
• Rectangular/Custom Shape

• Surface Finishing
• Smooth, Anti-Corrosion

• Surface Treatment
• Other, Zinc Plated / Powder Coated

• Thickness
• 3 mm

• Tolerance
• 0.1 mm

• Usage
• Industrial Fittings, Brackets, Support Components

• Weight
• Depend on size (approx. 0.5 - 2 kg each)

• Application
• Automotive, Electrical Panels, Construction, Machinery

• Capacity
• Varies based on application

• Coating Type
• Electroplated or Powder Coated

• Components
• Sheet Metal Bracket, Mounts, Base Plates

• Dimension (L*W*H)
• Customizable as per requirements

• Grade
• IS 2062, SS 304/316

• Hole Size
• Custom, as per design

• Making Process
• Other, CNC Laser Cutting, Bending, Welding, Stamping

• Material
• Other, Mild Steel (MS), Stainless Steel (SS)

• Mount Type
• Panel Mount, Surface Mount

• Shape
• Rectangular/Custom Profile

• Surface Finishing
• Smooth, Matt, Glossy

• Surface Treatment
• Other, Zinc Plated, Powder Coated, Galvanized

• Thickness
• 8 mm

• Tolerance
• 0.02 mm

• Usage
• Industrial and Mechanical Assemblies

• Weight
• Depends on design and dimension

• Application
• Rear door of vehicles

• Capacity
• High volume production (dependent on fabrication setup)

• Coating Type
• Primer/E-coat

• Components
• Main panel with reinforcement brackets and mounting holes

• Dimension (L*W*H)
• Custom as per design requirements (typically conforms to rear door dimensions)

• Grade
• IS 513 D/D or equivalent automotive grade

• Hole Size
• Typically 6-10 mm (customizable for hinge or mounting points)

• Making Process
• Other, Pressing, Punching, Welding

• Material
• Other, Mild Steel (MS) Sheet

• Mount Type
• Bolt-on and Weld-on

• Shape
• Sheet metal profile contoured to rear door assembly

• Surface Finishing
• Smooth, burr-free with anti-corrosive coating

• Surface Treatment
• Other, Electro-galvanized/primed

• Thickness
• 2 mm

• Tolerance
• 0.1 mm

• Usage
• Automotive body panel

• Weight
• Approx. 3.2-6 kg (depending on exact dimensions and reinforcements)
